Control heads

Extra safe in Ex-zones

With the digital KIESELMANN control heads "KI-Top", four valve positions can be controlled and reported. The integrated electronics controls the solenoid valve, detects status and returns it. The control heads consist of a bottom part with bayonet lock and a plastic or stainless steel cover (protection class IP 67).

Automate valves easily

The modular design of KIESELMANN valves makes it possible to convert to a pneumatic actuator with control head at any time. As a standard our actuators are equipped with mechanical position indicator and sensor mounting.

Power and brains: Actuators with KI-TOP control heads

Our control heads already contain control electronics and pilot valves. They support all common communication interfaces, such as PLC, AS-i and IO-Link, and can be connected via various ways, such as cable entry or M12 connectors.

The connection to the supply air is made by compressed air quick connector on the control head.

The control board can be fitted with an LED all-round display. For optimal visual control.

In areas with highly flammable and explosive substances, such as spirits, our TÜV tested control heads ensure maximum safety. Two versions are available: Zones 1 and 21 as well as 2 and 22, which comply with Directive 2014/34/EU. We also have control heads that comply with the NAMUR specifications.



• Modular, for all KIESELMANN valves

• Precise position sensing, optionally with automatic learning mode

• Control and reporting of up to 4 valve positions

• Fully automatic

• Optional: LED all-round display

• Optional: increased safety through emergency stop function



Versions

Control head with plastic hood

Control head with stainless steel hood

ATEX Control head
